Printhead Piezoelectric Printhead DX5/7/8 G 3.5PL
Printhead Height 10 cm MAX
Media Size 1300 x 1300 (mm)
Media Types Glass, Acrylic, Ceramic, Metal, Paper, Wood, Leather, PVC, PP, PE, PTFE…
Speed Nomal Quality  18 sqm/h
Speed Standard Quality  10 sqm/h
Speed Photo Quality 6 sqm/h
Ink Type UV Ink
Ink Color CMYK / CMYKLcLm / White or Varnish
Ink Capacity 500 ML per main tank of each color, Automatic ink quantity monitoring, non-stop with ink
Dry System UV_LED light system
Resolution 1440, 2160, 2880 dpi
Rip Software MainTop / PhotoPrint (Option)
PC Operation System Windows 7 32/64bit RAM≥8G
Environment Temperature: 18°C – 26°C ; Humidity : 40% – 60%
Power Supply Max 3.6KW, AC, 50/60Hz, 220V(±10%)>12A
Image Format TIFF, JPEG, EPS, PFD
Machine Size L2600 W2000 H1500 (mm)
Packing Size L2700 W2100 H1600 (mm)
Machine Weight 630 KG
Packing Weight 700 KG
