At a glance
- Working area
- 1300×1300 mm
- Power
- DX5/7/8
- Feature
- up to 2880 dpi
- Ideal for
- Glass, acrylic, metal, wood, leather, PVC
- Price from
- €20,300.00 + 24% VAT
Technical specifications
| UV PRINTER 1313 | |||
| Print head | Piezoelectric Printhead DX5/7/8 G 3.5PL | ||
|---|---|---|---|
| Max. object height | 10 cm MAX | ||
| Print area | 1300 x 1300 (mm) | ||
| Printing materials | Glass, acrylic, ceramic, metal, paper, wood, leather, PVC, PP, PE, PTFE… | ||
| Speed (normal quality) | 18 sqm/h | ||
| Speed (standard quality) | 10 sqm/h | ||
| Speed (photo quality) | 6 sqm/h | ||
| Ink type | UV ink | ||
| Ink colors | CMYK / CMYKLcLm / White or varnish | ||
| Ink tanks | 500 ml per main color tank, automatic level monitoring, refill without interruption | ||
| Drying system | UV LED lamp | ||
| Resolution | 1440, 2160, 2880 dpi | ||
| RIP software | MainTop / PhotoPrint (optional) | ||
| PC operating system | Windows 7 32/64bit RAM≥8G | ||
| Operating environment | Temperature 18–26 °C, humidity 40–60% | ||
| Power supply | Max 3.6 kW, AC, 50/60Hz, 220V(±10%)>12A | ||
| File formats | TIFF, JPEG, EPS, PDF | ||
| Machine dimensions | L2600 W2000 H1500 (mm) | ||
| Package dimensions | L2700 W2100 H1600 (mm) | ||
| Machine weight | 630 KG | ||
| Package weight | 700 KG |
View all professional UV Printers.
